Wireless Control LED Driver

LTDC25W700NZ-T2CH + WBDA

Description:

DALI dimmable LED Driver for constant current of 200 - 700 mA

Constant Current LED Driver 5 - 25 W

DALI-2 DT8 : 1500K-10000K, Dimming : 1-100%

Touch-Dim : 1500K-10000K, Dimming : 10-100%

Average service life 50,000 h

Easy and fast output current setting via NFC (Reader and Mobile Smartphone)

Download HEPXIDEA via mobile smartphone to easily control dimming

Operating ambient temperature -20°C - +50°C

Ripple current ±5%

Protection:

1. Short & open circuit proof

2. Auto. overheat regulation or cut off

3. Overload protection

4. SELV

Others:

CB Certificate NL-59579

ENEC Certificate 88-109200

EU Declaration of conformity CE LTDC Series

GB Declaration of conformity UKCA LTDC25 45W
